Atomos 7-inch monitor-recorder capturing 4K in ProRes/DNxHR to SSD via HDMI/SDI, with comprehensive monitoring tools.
The device features a 7-inch IPS touchscreen with a 1920×1200 pixel resolution and 350 cd/m² brightness. Recording is done in Apple ProRes (422, 422 HQ, 422 LT, 422 Proxy) and Avid DNxHR codecs onto 2.5-inch SSDs or CFast cards. HDMI 1.4 and 3G-SDI inputs support 4K up to 30fps, HD up to 60fps, and 2K up to 60fps. The internal battery (NP-F770) provides approximately 2 hours of operation; external power is supplied via 12-24V DC. Monitoring features include Waveform, Vectorscope, Histogram, False Color, Zebra, and Focus Peaking. The aluminum housing weighs 875 grams.
Atomos launched the Shogun in the fall of 2014 as the first 4K external recorder in the Ninja family. In 2015, the Shogun Flame followed with improved HDR support and 1500 cd/m² brightness. The Shogun Studio (2016) expanded the concept with 12G-SDI and rack-mount capabilities. In 2017, the product line was superseded by the Sumo 19", while in 2019, the more compact Ninja V redefined the 5-inch category. Atomos discontinued the original Shogun series in 2020 in favor of the Ninja V+ series.
Documentary filmmakers primarily use the Shogun for recording signals from cameras like the Canon 5D Mark IV or Sony A7S at higher quality than internal compression allows. For low-budget feature films, the device enables ProRes workflows even with consumer cameras. The large monitor facilitates focus pulling and image control for one-person crews. The added weight during handheld operation and limited battery life during exterior shoots are drawbacks. SSD recording significantly reduces media costs compared to professional recorders using P2 or XQD cards.
The Shogun is positioned between affordable HDMI recorders like the Blackmagic Video Assist and professional devices such as the Convergent Design Odyssey 7Q+. Compared to the smaller Atomos Ninja Assassin, it offers 4K recording and SDI inputs. Modern alternatives include the Atomos Ninja V+ with better HDR support or the Blackmagic Video Assist 12G for higher frame rates. Internal 4K recording in current cameras makes external recorders less essential, but ProRes workflows and monitoring features remain relevant arguments for dedicated devices.
Der Shogun erweitert meine Sony A7S um echte 10-Bit-Aufzeichnung und gibt mir endlich einen brauchbaren Monitor für präzise Belichtungskontrolle. Das False Color und die Waveform-Anzeige helfen mir besonders bei Available Light-Situationen, die korrekte Belichtung ohne Zebra-Flimmern zu beurteilen. Allerdings macht das zusätzliche Gewicht Gimbal-Arbeiten deutlich anspruchsvoller.
Mit dem externen Monitor kann ich während der Aufnahme viel besser die Bildkomposition und Schauspieler-Performance beurteilen, ohne ständig auf das kleine Kamera-Display schauen zu müssen. Die Möglichkeit, Playback direkt am Set zu machen, beschleunigt Entscheidungen über weitere Takes erheblich. Bei Interviews schätze ich die diskrete Positionierung des Monitors abseits der Kamera.
Der Shogun kostet etwa 1.500 Euro und amortisiert sich durch eingesparte Rental-Kosten professioneller Recorder bereits nach wenigen Drehtagen. Die günstigen SSD-Medien reduzieren die Materialkosten pro Drehtag um etwa 60% gegenüber P2-Karten. Allerdings benötige ich zusätzliche Akkus und einen robusten Transport-Case, was weitere 400 Euro Budget bedeutet.
1. Was beschreibt „Atomos Shogun" am besten?
2. Zu welchem Department gehört „Atomos Shogun"?
3. Wie viele verschiedene Fachperspektiven bietet dieser Eintrag?
